BS Roller Crusher
This is our new designed BS roller crusher with press rollers inside, with a better grinding performance than other traditional hammer mills.
3) Unique design, with a good grinding performance on oil materials.
|
Model |
BS150-3 |
BS150-4 |
BS250-3 |
BS250-4 |
BS500-3 |
BS500-4 |
|
Length（mm） |
780 |
780 |
920 |
920 |
1340 |
1340 |
|
Width（mm） |
670 |
670 |
720 |
720 |
1210 |
1210 |
|
Height（mm） |
1600 |
1850 |
1750 |
2000 |
2000 |
2250 |
|
Weight（kg） |
350 |
520 |
580 |
750 |
1200 |
1400 |
|
Capacity（kg/h） |
50-200 |
50-200 |
100-400 |
100-400 |
200-500 |
200-500 |
|
Motor (kw) |
2.2 |
3 |
5.5 |
7.5 |
11 |
15 |
|
Roller Diameter（mm） |
ϕ150 |
ϕ150 |
ϕ150 |
ϕ150 |
ϕ219 |
ϕ219 |
|
Roller Length(mm） |
150 |
150 |
250 |
250 |
500 |
500 |
Two Types of Rollers
1) Grid Roller for big raw material like walnut, almond...
2) Standard Roller for small raw material like flax, sesame...
Jiangyin Brightsail Machinery focuses on one-stop overall powder process solutions.
The solution covers from cleaning machine,cutting machine,dryer, roaster, crusher, grinding mill,mixer,to filling and packing
machines...etc.
Till 2023 year, we have exported our machines to more than 84 countries around the world and have received a lot positive
feed-backs from our customers.
Besides, we also provide other solutions for food and chemical powder processing.
Q: To get a detailed quote or to choose a suitable model grinder, what buyer shall provide?
A: 1) raw material name?
2) capacity the buyer needs to produce? kg/hr
3) target powder size the buyer needs? like 20 mesh, 30mesh, 40mesh,60 mesh.....etc
(if you don’t know, you can just tell us what will you grind)
Q: Will the machine explode while working?
A: Usually, no. If the powder is explosive or your local agency has specific requests, please contact us, we can provide anti-explosion solutions for your machine.
Q: Can the Roller Crusher machine’s voltage be customized into single phase, and family use?
A: Most machines cannot, but some machine can, please contact us to check and confirm.
Our Roller Crusher suitable for oily materials,
such as coffee beans, almonds, sesame seeds, etc...
This is our BS-150 Roller Crusher grinder coffee beans,
can make 10-40 mesh powder
And this is our BS Roller Crusher grinding black mustard seeds
