BSC Crushing Machine Primary Crusher
Introduction of BSC Coarse Crusher:
Our coarse crusher has two functions mainly:
(1) Crush raw materials into flakes or granules like ginger granules,chili flakes,tea granules,black pepper granules,biscuit flakes,herb granules...etc
(2) It is used as a primary crusher before grinding.
For example,if we need to make cinnamon powder, we shall crush the long and big cinnamon into pieces, then feed the pieces into pulverizer,otherwise the cinnamon is too big to be fed into the pulverizer.
Application and work method of BSC Coarse Crusher :
It’s applied in food,chemical and pharmaceutical lines.
Raw material is fed into the crush chamber through the feed hopper,then crushed and cut by the fixed and rotating knives in the chamber, and flows to the exit automatically under the effect of rotating centrifugal force.
There are two type discharge way, one is side way, one is bottom way.
Detailed Images:
1) The discharge part can be vertical type (on the back side), and table type (on the bottom).
2) Cutter inside the mill chamber.
These are pictures of inner part of our BSC Coarse Crusher :
Technical Data of BSC Coarse Crusher :
|
Model |
BSC-200 |
BSC-300 |
BSC-400 |
BSC-600 |
BSC-1000 |
|
Capacity(kg/h) |
80-300 |
100-800 |
200-1000 |
500-1500 |
1000-2500 |
|
Size of input granules (mm) |
<100 |
<100 |
<100 |
<100 |
<100 |
|
Crushing Fineness(mm) |
0.5-20 |
0.5-20 |
0.5-20 |
0.5-20 |
0.5-20 |
|
Rotor speed (rpm) |
530 |
530 |
530 |
530 |
540 |
|
Motor power(KW) |
3 |
5.5 |
7.5 |
11 |
15 |
|
Overall Size(L*W*H)(mm) |
600*500*1228 |
720*700*1303 |
900*700*1306 |
1020*700*1306 |
1330*850*1826 |
|
Weight(Kg) |
200 |
300 |
380 |
500 |
1000 |
Overall drawing of BSC Food Coarse Grains Crusher Konjac Into Granules Machine (side discharge type)
Pictures of BSC Coarse Crusher :
To avoid flying dust, a filter box is optional to be connected with the crusher;For big capacity crushing, a belt conveyor machine is recommended;
Before the belt conveyor, a metal detector machine is also optional and recommended.
Jiangyin Brightsail Machinery focuses on one-stop overall powder process solutions.
The solution covers from cleaning machine,cutting machine,dryer, roaster, crusher, grinding mill,mixer,to filling and packing machines...etc.
Till 2023 year, we have exported our machines to more than 84 countries around the world and have received a lot positive
feed-backs from our customers.
Besides, we also provide other solutions for food and chemical powder processing.
Q: Can the BSC Crushing Machine Primary Crusher machine size be customized?
A: Yes, maybe we can. You shall tell us the room size of your factory, so we can adjust the design to fit in your space, we can try it.
Q: Can I see the working BSC Crushing Machine Primary Crusher machine in user’s factory?
A: It depends, you shall contact our sales to check.
And most companies don’t allow strangers to visit their factory.Only a few allow,so please contact our sales to check whether it is possible.
Q: What is the material of the BSC Crushing Machine Primary Crusher?
A: Stainless steel 304 is our standard material.
Sometimes,we also use SS316 as customer requests.
In the video is our BSC-600 Crushing Machine Primary Crusher
we are using it to crush dried leaf into graunles.
This is BSC-600 Coarse Crusher purchased by our customer in India,
uses it to crush spice coarse powder/granules.
